Small Automatic Paste Liquid Honey Jam Butter Blister Packing Machine

Product Description

Product application

The DPP140 Blister packing machine is of flat-plate structure, with pressing, molding, meshes heat-sealing, adjustable travel range, for small size of body and ease of operation. It is applied to Al-Al, Al-PVC, Al-plastic packaging for capsule, table, candy, healthcare, small hardware etc. It is widely used in small pharmacy factory, preparation-room of hospital institute laboratory, mini-motor test workshop. The machine reaches advanced level in China.

It is suitable for capsule, tablet, honey pill, candy, liquid (ointment), paste as well as irregular shape Al-al Al-plastic and paper-plastic composite sealing packing in pharmacy, healthcare, food, cosmetics, medical equipment industry etc.

Model	DPP-80	DPP-140
Punch Frequency(times/min)	10-40	10-35
Production Capacity(plates/h)	2400	4200
Max. Forming Area and Depth(mm)	7*110*26	110*120*25
Travel Range(mm)	20-80	50-120
Standard Edition(mpa)	88*75	80*57
Air Pressure(kw)	0.6-0.8	0.4-0.6
Main Power(kw)	1.8	3.8
PVC Hard Tablet(mm)	0.15-0.5*88	0.15-0.5*140
PTP Aluminum(mm)	0.02-0.035*88	0.02-0.035*140
Mould Cooling	Tap water or recycle water	Tap water or recycle water
Overall Size(mm)	1500*600*1200	2300*560*1410

Detailed Images

Packing & Delivery

Certifications

Our factory

Contact us

Contact us: Emily Peng

Mobile phone : +86 13304197530

QQ : 7569360

Wechat: 13304197530

Liaoyang Zhonglian Pharmaceutical Machinery Co., Ltd. was established in 2001. The company is located in Liaoyang city, Liaoning province and covers total area of seven thousand square meters. The enterprise is specialized engaged in manufacturing and selling pharmaceutical machinery. We have a professional technical team and after-sales service team. The company have passed the ISO 9 0 0 1 Quality Management System Certification, CE Product Certification and obtained many Utility Model Patent Certification. At present, the products have been widely used in pharmaceutical, chemical, food, mining, textile, environment protection and many other industries. Through the unremitting efforts of all the staff, the company has formed its own sales network all over the world. The products have been exported to the United States, Greece, New Zealand, Australia, Canada, Venezuela, Peru, Russia, Singapore, Turkey, Japan, Korea, Thailand, Malaysia, Indonesia, Kenya, Seychelles and other countries. The staffs are committed to provide different solutions according to different users and different requirements. With reliable quality and after-sales service, the company won the support and praise of the broad masses of overseas customers. In recent years, the company has built a long-term and stable cooperation relationship with many strong manufacturing enterprises in China.
